This processor process a trigger wheel signal and outputs a sync pulse when a missing tooth (teeth) is detected. INPUTS. The DIGITAL signal comes to pin11. At the end of the missing tooth/teeth, 4 pulses are generated: – a positive and short pulse (10us) – a complementary negative and short pulse (10us) – a positive …
This unique device was created to assist a deaf motocross rider girl in feeling the engine, along with vibrations and throttle response. It turns on a green led if the engine revs are less than 3000rpm or a blue led if the revs are greater than 7000rpm. By moving two resistors through eight holes, those …
Here is how to read “Base Advance” and “Max Advance” just by reading the flywheel. The “T” mark is Top Dead Center The “F” mark is Fixed/Base Advance at idle. The “| |” mark is the range of Maximum Advance. When the timing is checked with a timing lamp, The “F” mark should appear to …
Digital RPM Meter with fancy features. RPM are displayed every 0.2 to 1 second (selectable) and also available on a USB connector. Connect the Tachometer to any Windows, Linux, Mac computer throughout a USB connection and terminal console to collect real-time RPM measures for further analysis on the long run. or choose to displayed RPM …
v1r4c0 with WiFi and DAC ! This Ignition Timing Meter is extremely valuable in repair work, engine tuning and CDI/TCI testing. It makes it easy to extract and analyze the advance timing of your ignition box. It offers an affordable, portable tool used in the field that doesn’t not require a rig or timing lamp …
